Tenda o3 - Wireless 2.5GHz 150Mbps Outdoor Access Point

Item Code : Tenda - o3



Product Details

Tenda™   WiFi Access Points Outdoor

Tenda - Tenda o3 - Wireless 2.5GHz 150Mbps Outdoor Access Point

Item Code: Tenda - o3

Brand: Tenda

Manufacturer: Tenda

Tenda - o3

Description

This outdoor wall or Pole mounted Wireless Access Point (WiFi Transmitter/Receiver) model Tenda o3 is a stable and easy-to-use wireless access point also allows wireless Point to Point systems of upto 5 Kilo Meter. It is suitable for WIFI coverage in outdoor areas in hotels, small and medium in size, bars, cafes, large houses, WiFi for the Garden. The Tenda o3 operates in the 2.4GHz band with wireless speeds of up to 150Mbps. The 03 has a 16dBi directional antenna to provide an efficient way to pick up and maintains a stable signal for a wireless network connection range up to 5 Kilo Meters. With the Simple design and elegant appearance, it can be directly installed on to walls or Mast Mounted. The o3 can also be implemented in Commercial WISP CEP Systems.

Tenda - o3

WiFi Access Point Tenda - o3

Specification

Specification
Dimension270*94.86*67.5mm
Frequency2.4GHz
Maximum wireless speed150Mbps
CPU ProcessorBroadcom 300MHz
Antenna BeamwidthHorizontal: 60°
Vertical: 30°
Waterproof LevelIP64
Remote Web accessSupport
Schedule RebootSupport
Page TimeoutSupport
Dyndns
oip
dyndns.org
Network DiagnosesPing
Traceroute
Signal Scan
Maximum Transmit Power800mw(29dbm)
Reception SensitivityMCS0: -88dbm
MCS7: -72dbm
Maximum Concurrent Clients15
Interface1*FE PoE/WAN/LAN port
1*FE LAN Port
Grounding Terminal
1*RST Button
3G Access12dbi Directional Antenna
Maximum Power Consumption6W
Lightning-proof4KV
LEDPWR
Bridge
LAN
WAN/LAN
Power SupplyPoE Injector (12v 1A,Cat5e or Better Ethernet Cable Length > 60 meters)
Operating ModeAP/Station/Universal Repeater/Repeater/P2MP/WISP/Router
Standard&ProtocolIEEE 802.11n/g/b
FeaturesEnable/Disable Wireless Radio
SSID Hidden
Wireless Client isolation

Sensitivity Threshold

WMM Capable
APSD Capable
Wireless Access Control
Wireless Client list
Security64/128 WEP
WPA-PSK
WPA2-PSK
WPA&WPA2-PSK
WPA
WPA2
Transmit PowerAdjustable power by 1dBm
DHCP ServerDHCP Server
Clients list
VPN Pass-throughPPTP
L2TP
Management Tool
Time&Date Setting
System Log
Firmware update
Backup/Restore Configuration
Username Managerment
Package Content
O3Power Adapter
PoE Injector
Ethernet cable
Quick Installation Guide
TemperatureOperating Temperature:-20℃ ~ 55
Storage Temperature:-40℃ ~ 70℃
HumidityOperating Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing
Default SettingsIP Address: 192.168.2.1
Login Username:admin
Login Password:admin
CertificationFCC
CE
RoHS
