IP Camera 5MP 2.8mm Lens , TM-5 UE White

Item Code : TM-5 UE White



Product Details

Technomate™   5 Mega Pixel - IP Camera

Technomate - IP Camera 5MP 2.8mm Lens , TM-5 UE White

Item Code: TM-5 UE White

Brand: Technomate

Manufacturer: UniView

.

Features

  • Optics

  • Starlight illumination
  • Day/night functionality
  • Up to 120dB WDR (Wide Dynamic Range)
  • Smart IR, up to 30m (98ft) IR distance
  • Compression

  • Ultra 265, H.264, MJPEG
  • Triple streams
  • 9:16 corridor format
  • Network

  • ONVIF Conformance
  • Structure

  • Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
  • Wide voltage range of ±25%
  • 4KV surge protection designed for network interface
  • IP67
  • 3-Axis

Specification

Camera

Sensor 1/2.7",
5.0 megapixel,
progressive scan,
CMOS
Lens 2.8mm@F1.6
DORI Distance Lens 2.8mm
Detect 63m
Observe 25.2m
Recognize 12.6m
Identify 6.3m
Angle of view (H) 105.3°
Angle of View (V) 69.5°
Angle of View (O) 136.8°
Adjustment angle Pan 0° ~ 360°
Tilt 0° ~ 90°
Rotate 0° ~ 360°
Shutter Auto/Manual, 1 ~ 1/100000s
Minimum Illumination Colour: 0.005Lux (F1.6, AGC ON)
0Lux with IR
Day/Night IR-cut filter with auto switch (ICR)
Digital noise reduction 2D/3D DNR
S/N >52dB
IR Range Up to 30m (98ft) IR range
Defog Digital Defog
WDR 120dB

Video

Video Compression Ultra 265,
H.264,
MJPEG
H.264 code profile Baseline profile,
Main Profile,
High Profile
Frame Rate Main Stream: 5MP (2592*1944), Max 20fps;
4MP (2560*1440), Max 30fps;
3MP (2048*1536), Max 30fps;
2MP (1920*1080), Max 30fps;
Sub Stream: 2MP (1920*1080), Max 30fps;
Third Stream: D1 (720*576), Max 30fps
HLC Supported
BLC Supported
9:16 Corridor Mode Supported
OSD Up to 8 OSDs
Privacy Mask Up to 8 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas

Audio

Audio Compression G.711
Suppression Supported
Sampling Rate 8KHZ

Network

Protocols IPv4,
IGMP,
ICMP,
ARP,
TCP,
UDP,
DHCP,
PPPoE,
RTP,
RTSP, RTCP,
DNS,
DDNS,
NTP,
FTP,
UPnP,
HTTP,
HTTPS,
SMTP,
802.1x,
SNMP,
QoS
Compatible Integration ONVIF (Profile S, Profile T),
API

Interface

Network 1 RJ45 10M/100M Base-TX Ethernet
Built-in Mic Supported

General

Power DC 12V±25%, PoE (IEEE 802.3af)
Dimensions (Ø x H) F126 x 94mm (Ø5.0” x 3.7”)
Weight 0.45kg (0.99lb)
Operating Conditions -30°C ~ 60°C (-22°F ~ 140°F),
Humidity: =95% RH (non-condensing)
Ingress Protection IP67
